DC Fast & Ultra-Fast Chargers
From 30kW to 240kW.
Built for today. Ready for tomorrow.
Our DC fast chargers deliver high power, unmatched reliability, and intelligent performance for every commercial and public charging need.
Interactive Configurator
Build your charger.
See specs update in real time.
Tell us where you're deploying and how much power you need — we'll assemble the right Sonar EV configuration and route your enquiry to the engineering team.
01
Where will it be deployed?
02
Choose power capacity
60kW Recommended
03
Connector setup
Guns
Connector types
04
Deployment environment
Live
Your configuration
60kW
60kW DC Fast Charger
Compact. Powerful. Built for Performance.
- Use case
- Hotel / Resort
- Guns
- Dual Gun
- Connectors
- CCS2
- Deployment
- Outdoor / IP55
Full specifications
| Model | Sonar.EV 60kW DC Fast Charger |
| Max DC Output Power | 60 kW |
| DC Output Voltage | 150 – 1000 V |
| Max DC Output Current | 200 A |
| Number of Output | Dual Gun |
| EVs Supported | 2 × 30 kW each OR 1 × 60 kW |
| Efficiency | Up to 96% (Peak) |
| Power Factor | ≥ 0.99 at full load |
| THDi | ≤ 5% |
| Communication Protocol | OCPP 1.6J |
| Network Connectivity | GSM (3G/4G), Wi-Fi, Bluetooth |
| User Authentication | RFID / QR Code / Mobile App |
| Display | 7" LCD Touch Panel |
| Protection | Overcurrent, Overvoltage, Undervoltage, Ground Fault, Short Circuit, Surge Protection, DC Leakage |
| Operating Temperature | -35°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Humidity | ≤ 95% RH, Non-condensing |
| Altitude | Up to 2,000 m (Derating above 2,000 m) |
| Cooling | Forced Air Cooling |
| IP Rating | IP55 |
| Dimensions (W×D×H) | 620 × 260 × 1500 mm |
| Weight | ≤ 150 kg |
| Compliance | IEC 61851-1, IEC 61851-23, IEC 62196, CE |
Every Sonar EV Charger
Engineered for uptime, safety, and scale
IP55 Rated
OCPP 1.6J
GSM / Wi-Fi / BT
7" Touch Display
RFID / QR / App
-35 to +55°C
Up to 96% Efficient
IEC & CE Certified
